QUALITY IS EVERYTHING
| Place of Origin: | China |
|---|---|
| Brand Name: | Linsheng Auto II MaxM |
| Certification: | CE,FCC by SGS |
| Model Number: | LS-PAT-6+LS-RSK-H1 |
| Minimum Order Quantity: | 1 piece |
| Price: | Negotiable |
| Packaging Details: | Carton |
| Delivery Time: | 2 weeks |
| Payment Terms: | L/C, T/T, PayPal |
| Supply Ability: | 1000pcs/month |
| Voltage: | 12V / 24VDC | Max. Loading: | 1000N / 100KG |
|---|---|---|---|
| Max Speed At No Load: | 64mm/s | Max. Speed At Full Load: | 18mm/s |
| Stroke: | 180mm~800mm | Limit Switch: | Built In |
| Signal Output: | Hall Sensors | Control Box Feature 1: | Wired Switch And Remote Dual Operation |
| Control Box Feature 2: | Inbuilt Overloading Safety Protection | Control Box Feature 3: | Synchronize Two Hall Linear Actuators |
| Highlight: | 28V Hall Effect Actuator Control Box,100KG Force Actuator Control Box |
||
Hall Effect Actuator Control Box 12V~28V Synchronize 100KG Force DC Linear Motors
This 3-stage pillar-style actuator is designed for indoor use in applications such as furniture and kitchens, with no specific IP rating. It supports a maximum load of 1000N and delivers a movement speed of 18mm/s under full load. When paired with the LINSHENG LS-RSK-H1 control box, it offers a seamless plug-and-play experience, allowing easy synchronization of two motors using either a remote control or a wired switch.
Specifications:
|
Control Unit LS-RSK-H1
|
Electric Actuator LS-PAT-6
|
|
Voltage: 12V~28VDC Max. current: 25A Control way: Switch and remote control Frequency: 433.92MHz Remote range: 30 meters Safety protection:Inbuilt New remotes: Programmable Feature: Synchronize 2 Hall actuators
|
Voltage: 12V/24VDC Max. loading: 1000N/100KG Max speed: 18mm/s (full load) ; 64mm/s (no load) Stroke: 180mm~800mm Retracted length: ≧ S/2+165mm Limit switch: Inbuilt Signal output: Hall sensors IP rate: NO Duty cycle: 10% |
Features:
About us:
Linsheng Auto (LINSHENG INTERNATIONAL ENTERPRISE CO.,LTD) is specialized in Auto motion, motion remote control systems, automobile safety and security electronics for more than 10 years. With an experienced R&D department of 19 engineers team, we can provide customized design and molding to support your OEM/ODM projects.
Support and Services:
All our products come with a one-year warranty. We provide technical support and services for Linear Actuator Controllers. Our team of engineers and technicians are available to help you troubleshoot any problems you may be having with your Linear Actuator Control box.
Packing and Shipping:
All our products are packaged carefully before shipping. The box is sealed with tape and labeled with the product name and shipping address. Your item will be shipped via UPS, FedEx , DHL or other shipping courier you may prefer.
